70a Bi-directional Esc Pair 6-ch Radio Combo 2-6s Air-cooled For Rc Boat/ Car

◆ DS600 remote controller 2.4G, 6-channel fishing boat, net pulling boat with constant speed voltage signal feedback

◆ 2 different plugs: XT60 plug and T plug, choose the appropriate plug according to battery needs

◆

◆ Kit accessories list:

◆ 2 70A air-cooled brushless ESCs

◆ DS600 remote control 1 set

◆ Voltage parallel Y line 1

◆

◆ Brushless ESC: 70A air-cooled brushless ESC

◆ Voltage: Support voltage 2S-6S

◆ Mode: Bidirectional, forward and reverse, no brake

◆ Parameters: UBEC 5V 3A can drive 2 25kg servos

◆ The ESC uses a 32-bit processor

◆ With temperature protection (80 degrees) After overheating, the maximum output will be limited to 30% and the red light will be on

◆ It is not a 7805 linear regulator, so two ESCs cannot power the receiver at the same time.

◆ Note: If multiple ESCs are connected to one receiver, only one ESC should be used to power the receiver. You need to cut off the red wire in the middle of the other ESC signal cables to avoid voltage conflicts.

◆ Operation mode: Bidirectional

◆ Number of lithium batteries: 2S-6S (7s is not supported / two 12v batteries cannot be connected in series)

◆ BEC: Built-in BEC 5V 3A

◆ plug:

◆ No plug: ESC has soldered wires, no plug

◆ T plug + 4mm banana plug

◆ XT60 plug + 4mm banana plug
